Buy the impressive Fenix BC30 V2.0 front bike light and receive a separately packaged Fenix BC05R V2.0 rear light worth £22.95 absolutely free in this seasonal promotion offer ! A Fenix ARE-A2 mains charger and 2 x Fenix ARB-L18-3400, 18650 batteries are also included to complete the outfit.
Please note: Laser engraving for this product applies to BC30 v2.0 only.
Fenix BC30 V2.0 twin LED bike light features wireless remote control, enabling the light to be operated by either the on board switch or the wireless handlebar remote. Great for bar mounting or as a remote controlled helmet mounted light with the Fenix ALD-08 helmet mount (available separately)
The light can be powered by either 2 x 18650 button top rechargeable Lithium Ion batteries (recommended) or four CR123 non rechargeable batteries. Batteries are easily replaceable via the securely lockable slide out battery carrier so it's easy to swap cells and keep night riding for hours. (please note that no batteries are supplied)
Two Luminus SST40 N5 LED's give a choice of 4 light outputs from 50 to 1500 lumens in Continuous Mode and a 2200 lumens Burst Mode. Fenix proprietary Dual-Distance-Beam System projects both near and far distance lighting enabling BC30 V2.0 bike light to deliver excellent performance on road or trail.
Built from tough aircraft grade aluminium, the light body and head offer excellent heat dissipation for extended high output run times and very long service life. Fenix BC30 V2.0 is impervious to the worst of weather being completely waterproof to a depth of 1 metre for half an hour.
• Wireless remote control offers instant burst output and selection of 4 brightness levels
• The supplied quick release bar mount fits handlebars from 22-35mm
• ALD-08 helmet mount available separately
• Wide operating temperature from -35 to 45 centigrade
• LED battery meter built into main switch
• LED low battery voltage warning (main switch flashes red)
• Overheat protection reduces output when temperature reaches 65C for long service life
• Ideal for road cycling, off road cycling and trail riding
Please note: 18650 rechargeable batteries and charger are not included. Button top batteries are required due to the battery carrier design. Please refer to related products below.
For full product details please refer to the user manual in the images area.
Fenix BC05R V2.0 is a dual purpose rechargeable rear bike light / safety marker light. The light can be fixed to seat posts of 20-35mm diameter with the included high elasticity ladder strap, or used as a red indicator / safety marker light with the supplied body clip accessory.
BC05R V2.0 features a 400 mAh internal Li-poly battery that is charged using the supplied USB to USB-C cable and your mobile phone charger, computer or external power pack. Charging time is just 1.5 hours from a 1A charger.
The light is fully weatherproof to IP66 standard and significantly improves on the original Fenix BC05R, offering 50% more brightness, 67% more run time and a wider field of view, increased from 120 to 180 degrees for added safety.
BC05R V2.0 features 6 output levels:
Low Constant - 5 lumens (16 hrs)
Low Flash Slow - 5 lumens (80 hrs)
Low Flash Fast - 5 lumens (150 hrs)
High Constant - 15 lumens (4.5 hrs)
High Flash Slow - 15 lumens (25 hrs)
High Flash Fast - 15 lumens (35 hrs)
Specification
Model
BC30 V2.0
Battery Type
18650
Battery Quantity
2
Additional Battery Type
4 x CR123 non-rechargeable (Do NOT use rechargeable 3.7v CR123 / RCR123 / 16340 batteries in this product)
Push button on / off / mode switch plus wireless remote switch with full mode selection
Construction
A6061-T6 aircraft grade aluminum
Finish
Premium Type III hard-anodized anti-abrasive finish (aluminium surfaces)
Tail Stand
No
Pocket Clip
No
Waterproofing
IP67, 1m depth & dustproof
Dimensions/Weight
120mm (Length) x 50.5mm (Width) x 31.8mm (Height)
154 grams (excluding batteries and mount)
Further Info
N/A
Operation
Fenix BC30 V2.0 operation:
Bicycle light Switch:
On/Off:
Press and hold the functional switch for 0.5s to turn on/off the light.
Output Selection:
With the light switched on, single click the functional switch to cycle through EDC/Eco-Low-Med-High.
Flash:
With the light switched on, double click the functional switch to enter flash mode; single click the functional switch again to exit flash mode.
Battery level Indication:
With the light switched off, single click the functional switch to check the battery status. The battery status percentage will be displayed, and then go out in 3 seconds.
Green light = constant on (saturated): 100% - 80% Orange light = constant on (sufficient): 80% - 40% Red light constant on (poor): 40% - 10% Red light flashes: 10% -0%
Wireless Remote Switch:
Switches:
Output selection switch and Burst switch:
Connecting with BC30 V2.0:
First Connection:
Press and hold the functional switch for 5 seconds, and the switch will flash red and green alternately, then single click either of the wireless switches and the bicycle light will light up to indicate connection is completed.
Note:
1. After the first connection, the wireless remote switch automatically memorizes the paired status. There is no need to match again afterwards. 2. The linear distance between the light and the wireless switch should not exceed 1.5 meters during the pairing process.
Output Selection:
With the light switched on, press and hold the output selection switch for 0.5s to enter/exit standby status, single click to cycle through EDC/Eco→Low→Med High. The light will automatically shut down after 10 minutes of stand by without any operation.
Instant Burst:
With the light switched on, single click the burst switch to enter the Burst mode of 2200 lumens, which will last up to 30s. Within 30s, single click any switch to exit Burst mode.
Note: If the battery level is low, BC30 V2.0 will light up with the highest brightness supported by the current battery level.
Wireless remote battery replacement:
Insert a coin Into the back of the wireless switch, rotate the coin counterclockwise to open the battery cover; and then insert the battery, and tighten the back cover clockwise. ▲ Note: Change the CR1632 button battery every 3 months.
Fenix BC05R V2.0 operation:
Operation is via a single button on the front of the light with built-in LED's that act as charging and battery level indicators.
• Press and hold the switch for 0.5 seconds to turn on / off the light. • With the light switched on, single press the switch repeatedly to cycle through Low constant - Low slow flash - Low fast flash - High constant - High slow flash and High fast flash modes.
